Coefficient Of Friction Tester
Optimise your production process by testing the COF Values of your Films.
The Coefficient of Friction (COF) Tester is a precision laboratory instrument used to measure the static and kinetic friction between two material surfaces. In the packaging industry, COF testing plays a critical role in evaluating the slip characteristics of plastic films, laminates, paper, and flexible packaging materials.
At Flexitest, we supply advanced Labthink COF Testers designed to comply with international standards and deliver highly accurate, repeatable results for quality control and R&D applications.
Coefficient of Friction Tester -MXD 02
The MXD-02 Coefficient of Friction Tester efficiently measures both static and kinetic friction across a diverse range of materials including plastic films, sheets, rubber, paper, and fabric. It is essential for assessing the smoothness of materials like metal-plastic composite strips, conveyor belts, and coatings to ensure quality control and compliance with application requirements.
Submit Your Details to Download Brochure!
Features
- Static and kinetic coefficients of friction can be tested for each specimen
- This instrument conforms to multiple standards of ISO, ASTM and GB and the user could select test methods as required
- Test speed could be preset and adjusted by the users as required
- Sled of specific weight could be customized
- The sliding plane and the sled are treated by degaussing and remanence detection which effectively reduce the system error
- Top quality parts and components made by world famous brands are used to ensure reliable overall product performance
- This instrument is controlled by micro-computer with LCD display, PVC operation panel and menu interface
Friction Peel Tester C620H
Optimise your production process by testing the COF Values of your Films.
The C620H Friction / Peel Tester is a versatile instrument used in the packaging industry to measure the coefficient of friction (COF) and peel strength of various materials.
The instrument features an innovative design with automatic sled lifting, enhancing testing accuracy and repeatability. Its high-end, easy-to-use embedded computer-controlled system ensures user-friendly operation. It conforms to multiple ISO, ASTM, and GB standards.
Submit Your Details to Download Brochure!
Features
- Automated Sled Lifting for Enhanced Accuracy
- Dual Test Modes: Friction & Peel
- Precision Sled Still Time for Repeatability
- High-Precision Temperature Control
- Global Standard Force Measuring System
- Intelligent Safety Features
- Compliant with ISO, ASTM, GB Standards
- User-Friendly Embedded Computer System
Select the right product for your specific requirements
← Swipe to compare both models →
| MXD-02 COF Tester | C620H Friction / Peel Tester | |
|---|---|---|
| Standard | ISO 8295, ASTM D1894 | ISO 8295, ISO 8510-2, ASTM D1894 |
| Testing Items | COF test | COF & peel test (use customized fixture) |
| Testing Speed | 100 & 150 mm/min | 0–500 mm/min |
| Stroke | 70 mm & 150 mm | 10–300 mm |
| Connection Rope | Nylon monofilament or Steel wire | Nylon monofilament or Steel wire |
| Capacity Range | 0–5 N | 0–5 N (standard); 0–10/30/50/100 N (optional) |
| Force Accuracy | 0.5% of Full Scale | Displayed Value ±0.5% (10%FS–100%FS); ±0.05%FS (0%–10% of load cell range) |
| Mass of Sled | 200 g; 500 g (optional) | 200 g |
| Sled Touching Surface | Felt or Sponge Rubber | Felt or Sponge Rubber |
| Heating Function | N/A | Room temperature – 100°C |
| Control | Microcomputer LCD; software (optional) | Embedded control system + Tablet |
FAQ's
Frequently Asked Questions (FAQs) – Coefficient of Friction (COF) Tester
What is a Coefficient of Friction (COF) Tester?
A Coefficient of Friction (COF) Tester is a laboratory instrument used to measure static and kinetic friction between two material surfaces. It helps packaging manufacturers control slip properties to ensure smooth machine operation and stable product stacking.
What does the MXD-02 Coefficient of Friction Tester measure?
The MXD-02 COF Tester measures:
Static COF – Force required to initiate sliding
Kinetic COF – Force required to maintain sliding
It is widely used for plastic films, laminates, paper, rubber, and flexible packaging materials.
How does the MXD-02 COF Tester work?
The MXD-02 operates on the horizontal plane method. A weighted sled is placed on the test material and pulled at a constant speed. The system records maximum and average force values to calculate static and kinetic coefficients of friction automatically.
What is the C620H Friction & Peel Tester used for?
The C620H Friction & Peel Tester performs both:
Coefficient of Friction testing
Peel strength testing
It evaluates slip characteristics and seal integrity in flexible packaging materials.
What is the difference between MXD-02 and C620H?
The MXD-02 is dedicated to static and kinetic friction measurement.
The C620H performs both friction testing and peel strength testing, making it ideal for laminated and heat-sealed packaging structures.
Which international standards do these testers comply with?
Both MXD-02 and C620H comply with international standards such as:
ASTM D1894
ISO 8295
TAPPI T815
TAPPI T816
This ensures accurate and globally accepted test results.
Why is friction testing important in packaging?
Friction testing prevents machine jamming, improves packaging line efficiency, and ensures stable stacking during storage and transport. Proper COF levels reduce production downtime and packaging defects.
Why is peel strength testing important?
Peel testing ensures proper heat seal strength and lamination bond integrity. It helps prevent delamination, leakage, and seal failure in food and pharmaceutical packaging.
What industries use MXD-02 and C620H testers?
These instruments are widely used in:
Flexible packaging industry
Plastic film manufacturing
Pharmaceutical packaging
FMCG packaging
Food packaging labs
Quality control and R&D laboratories
Why choose Flexitest for COF and Peel Testing Equipment?
Flexitest supplies genuine Labthink testing instruments with installation support, NABL-traceable calibration, application consultation, and PAN-India service network for reliable long-term performance.
What is the best tester for both friction and peel strength testing?
Flexitest supplies genuine Labthink testing instruments with installation support, NABL-traceable calibration, application consultation, and PAN-India service network for reliable long-term performance.
