Engineered for Reliability, Built for Accuracy

Vibration Test systems subject a product to varying degrees of rapid movement, allowing researchers to pinpoint the point at which the object’s structure or functionality is jeopardized. Laboratories can find preventive measures to increase their products’ durability and market value with our intuitive shaker machines.

World’s leading supplier of high reliability vibration test systems

Auto Vibration Test System

Vibration principle :

The basic principle is the amplitude of the vibration of a sine function with time, usually with an acceleration; displacement; speed, these. quantities to represent the vibration is horizontal.

Auto Vibration Test System

The vibration experienced by electrical and electronic products during transportation is mainly random type. The random vibration has wider frequency domain than sinusoidal vibration and it is a continuous spectrum. It can simultaneously excite the products using vibration of al frequency and clone the real environment.

Auto Vibration Test System

Sine sweep Test :

Some law continuously changing frequency of the excitation test product, aimed at the assessment of the frequency range to find cause-specific resonance frequency.

Auto Vibration Test System

The impact and collision impact all belong to the category, provisions of shock pulse impact test is used to determine the main components’ equipment and other products in the use and transportation process subjected to repeated (collision is repeated) and evaluate the applicability of packaging to protect the mechanical shock.

Our Solutions for Vibration, Shock and Drop Testing

We offer a wide variety of testing equipment systems including vibration, shock, drop, and combined testing, and provide the most suitable testing solutions for your needs. Trust our high-quality testing equipment to help ensure the safety and reliability of your products.

Pre-sales:
• Technical consultation: test method, laboratory planning and suggestion.
• Equipment selection: selection scheme, FAQ.
• Product testing scheme.

After Sales:
• Technical training: operation of equipment, daily maintenance, common fault diagonsis and troubleshooting.

• Scheduled on-site service: detection of problem as soon as possible in order to eliminate equipment &
anthoropogenic hazards. This is to ensure long term and stable Equipment operation as well as delivery of
latest technical information.

• Techinical support: special paid services are provided according to customer’s needs.

Vibration Test Systems

Specification Comparison — Electrodynamic · Environmental · Standard · Water Cooled

← Scroll to compare all systems →
Specification Electrodynamic Vibration Test System Environmental Vibration Test System Standard Vibration Test System Water Cooled Vibration Test System
Performance
Frequency range 2 – 3,000 Hz 2 – 2,500 Hz 2 – 2,000 Hz 2 – 3,000 Hz
Sine force (pk) 1 kN – 100 kN 1 kN – 50 kN 0.5 kN – 20 kN 10 kN – 200 kN
Random force (rms) 0.7× – 1× sine rating 0.7× sine rating 0.7× sine rating 0.7× – 1× sine rating
Max acceleration (sine) Up to 100 g Up to 80 g Up to 60 g Up to 100 g
Max velocity (sine) Up to 2.0 m/s Up to 1.8 m/s Up to 1.5 m/s Up to 2.0 m/s
Max displacement (pk-pk) Up to 76 mm Up to 51 mm Up to 51 mm Up to 76 mm
Table & Payload
Armature table diameter 200 – 700 mm 200 – 500 mm 150 – 400 mm 300 – 900 mm
Rated payload 10 – 500 kg 10 – 300 kg 5 – 150 kg 50 – 1,000 kg
Slip table available Yes (horizontal testing) Yes (horizontal testing) Optional Yes (horizontal testing)
Cooling & Power
Cooling method Air cooled (blower) Air cooled (blower) Air cooled (blower) Water cooled (closed loop)
Power supply 3-phase 415 V / 50 Hz 3-phase 415 V / 50 Hz Single / 3-phase 230–415 V 3-phase 415 V / 50 Hz
Amplifier type DSP-based linear amplifier DSP-based linear amplifier DSP-based linear amplifier DSP-based linear amplifier
Control & Standards
Control modes Sine, Random, Shock (SRS), Resonance dwell Sine, Random, Shock (SRS), Combined temp+vib Sine, Random, Shock (SRS) Sine, Random, Shock (SRS), Resonance dwell
Applicable standards IEC 60068-2-6, IEC 60068-2-64, ISO 16750-3 IEC 60068-2-6/64, MIL-STD-810, ISTA IEC 60068-2-6/64, ISO 16750-3 IEC 60068-2-6/64, ISO 16750-3, MIL-STD-810
Best Suited For
Typical automotive use ECU, sensors, connectors, actuators, general component vibration testing Combined temperature + humidity + vibration (HALT/HASS, climatic vibration) Small components, PCBs, R&D screening, incoming QC Heavy assemblies, powertrain, battery packs, large subframes
Installation area Medium floor space, air exhaust required Larger — climate chamber integration needed Compact, benchtop or small floor unit Large floor space, cooling water supply required
Electrodynamic General-purpose ▲
Environmental Temp + vibration ▼
Standard Compact R&D ▼
Water Cooled Heavy-duty ▼
⚡
Electrodynamic
Vibration Test System
Performance
Frequency range2 – 3,000 Hz
Sine force (pk)1 kN – 100 kN
Max accelerationUp to 100 g
Max displacementUp to 76 mm pk-pk
Table & Payload
Table diameter200 – 700 mm
Rated payload10 – 500 kg
Control & Standards
ModesSine, Random, Shock, Resonance dwell
StandardsIEC 60068-2-6/64, ISO 16750-3
Best For
Typical useECU, sensors, connectors, actuators, component vibration testing
🌡
Environmental
Vibration Test System
Performance
Frequency range2 – 2,500 Hz
Sine force (pk)1 kN – 50 kN
Max accelerationUp to 80 g
Max displacementUp to 51 mm pk-pk
Table & Payload
Table diameter200 – 500 mm
Rated payload10 – 300 kg
Control & Standards
ModesSine, Random, Shock, Combined temp+vib
StandardsIEC 60068-2-6/64, MIL-STD-810, ISTA
Best For
Typical useHALT/HASS, climatic vibration testing
🔬
Standard
Vibration Test System
Performance
Frequency range2 – 2,000 Hz
Sine force (pk)0.5 kN – 20 kN
Max accelerationUp to 60 g
Max displacementUp to 51 mm pk-pk
Table & Payload
Table diameter150 – 400 mm
Rated payload5 – 150 kg
Control & Standards
ModesSine, Random, Shock (SRS)
StandardsIEC 60068-2-6/64, ISO 16750-3
Best For
Typical useSmall components, PCBs, R&D screening, incoming QC
💧
Water Cooled
Vibration Test System
Performance
Frequency range2 – 3,000 Hz
Sine force (pk)10 kN – 200 kN
Max accelerationUp to 100 g
Max displacementUp to 76 mm pk-pk
Table & Payload
Table diameter300 – 900 mm
Rated payload50 – 1,000 kg
Control & Standards
ModesSine, Random, Shock, Resonance dwell
StandardsIEC 60068-2-6/64, ISO 16750-3, MIL-STD-810
Best For
Typical useHeavy assemblies, powertrain, battery packs, large subframes

Need help selecting the right Vibration Test System?

Share your component size, payload, test standard and force requirement — we'll recommend the right system for your automotive testing lab.
