Benchtop YS 6060
ys6060 product banner mobile
YS6060 reflectance and transmittance colour measurement

Features a 7-inch TFT touch screen, Bluetooth 2.1, and a Double Array 256 Image Element CMOS Sensor. It offers versatile spectrum analysis, auto-identifying, and customizable measuring apertures for precise colour measurement and transmission.

Ensure flawless paint quality with our color spectrophotometers. Achieve perfect color consistency and match across all vehicle parts effortlessly. Reduce waste and save costs with precise color control. Enhance customer satisfaction with stunning, uniform finishes every time.

Features

Select the right product for your specific requirements

Complete technical specifications for the YS6060 Benchtop Spectrophotometer — precision color measurement with integrating sphere geometry, wide wavelength range, and multi-standard compliance.

Specification YS6060 Benchtop Spectrophotometer
Optical System
Optical Geometry Reflect: di:8°, de:8° (diffused illumination, 8-degree viewing angle)
SCI (specular component included)/SCE (specular component excluded); Include UV / excluded UV light source
Transmittance: di:0°, de:0° (diffuse illumination, 0° viewing)
SCI (specular component included)/SCE (specular component excluded); Include UV / excluded UV light source; Haze (ASTM D1003)
Conforms to: CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO 7724/1, ASTM E1164, DIN5033 Teil7
Integrating Sphere SizeØ154 mm
Light Source360 nm to 780 nm, Combined LED Light; 400 nm cut-off light source; 420 nm cut-off light source
Spectrophotometric ModeConcave Grating
Sensor256 Image Element Double Array CMOS Image Sensor
Wavelength
Wavelength Range360 – 780 nm
Wavelength Interval10 nm
Semiband Width5 nm
Measurement
Measured Reflectance Range0 – 200%
Measuring Aperture Reflective: Ø30 mm / Ø25.4 mm, Ø18 mm / Ø15 mm, Ø10 mm / Ø8 mm, Ø6 mm / Ø4 mm
Transmissive: Ø25.4 mm
Remark: 1. Automatic identification of switch caliber   2. Customized configuration caliber and lens position
Specular ComponentReflectance: SCI & SCE  /  Transmittance: SCI & SCE
Measuring TimeAbout 2.4 s (Measure SCI & SCE about 5 s)
Colorimetry
Color SpaceCIE LAB, XYZ, Yxy, LCh, CIE LUV, Munsell, s-RGB, HunterLab, βxy, DIN Lab99
Color Difference FormulaΔE*ab   ΔE*uv   ΔE*94   ΔE*cmc(2:1)   ΔE*cmc(1:1)   ΔE*00   DINΔE 99   ΔE (Hunter)
Other Colorimetric Index WI (ASTM E313, CIE/ISO, AATCC, Hunter)
YI (ASTM D1925, ASTM 313)
MI (Metamerism Index)
Staining Fastness, Color Fastness, Color Strength, Opacity
8° Glossiness, Gardner Index, APHA / Pt-Co Index, 555 Index, Haze (ASTM D1003), Saybolt, Color code (ASTM D1500)
Observer Angle2° / 10°
IlluminantD65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, DLF, TL83, TL84, TPL5, U30
Displayed DataSpectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Offset
Repeatability & Accuracy
Repeatability Spectral reflectance: Ø25.4 mm/SCI, Standard deviation within 0.04% (400 nm to 700 nm: within 0.04%)
Chromaticity value: Ø25.4 mm/SCI, Standard deviation within ΔE*ab 0.01 (when a white calibration plate is measured 30 times at 5-second intervals after white calibration)

Spectral Transmittance: Ø25.4 mm/SCI, Standard deviation within 0.05% (400 nm to 700 nm: within 0.04%)
Chromaticity value: Ø25.4 mm/SCI, Standard deviation within ΔE*ab 0.02 (when a white calibration plate is measured 30 times at 5-second intervals after white calibration)
Inter-instrument ErrorØ25.4 mm/SCI, within ΔE*ab 0.12 (average for 12 BCRA Series II color tiles)
Display & Interface
Display7-inch TFT color LCD, Capacitive Touch Screen
Data PortUSB & Bluetooth & Print serial port
Data StorageStandard 5,000 Pcs; Sample 40,000 Pcs
LanguageSimplified Chinese, Traditional Chinese, English (Optional: German, French, Spanish)
Physical & Electrical
Dimension (L × W × H)370 × 300 × 200 mm
WeightApprox. 9.6 kg
PowerAC 24V, 3A power adapter
Illuminant Life Span5 years, more than 3 million times measurements
Environment
Operating Environment0 – 40°C, 0 – 85% RH (no condensing), Altitude < 2,000 m
Storage Environment-20 – 50°C, 0 – 85% RH (no condensing)
Application
ApplicationAccurate analysis and transmission of laboratory color. Used in paints, inks, textiles, garments, printing and dyeing, printing etc. industries for color transfer and quality control.
Accessories
Standard Accessory Power Adapter, User Guide, CD Disk (PC Software), USB cable, Standard Calibration Board, Black Calibration Cavity, Transmission black baffle, Sample holder, 25.4 mm caliber, 15 mm caliber, 8 mm caliber, 4 mm caliber, Transmissive Test Component, Micro Aperture (4 mm) transmission test clamp component
Optional AccessoryMicro-printer, Instrument inversion components, Culture dish
NotesThe specifications are subject to change without notice.
YS6060 Benchtop Spectrophotometer
Integrating Sphere · Ø154 mm · Concave Grating
Optical System
Sphere SizeØ154 mm
Light Source360–780 nm Combined LED; 400 nm & 420 nm cut-off
ModeConcave Grating
Sensor256 Element Double Array CMOS
Geometrydi:8°/de:8° · SCI/SCE · UV incl./excl.
Wavelength
Range360 – 780 nm
Interval10 nm
Semiband Width5 nm
Measurement
Reflectance Range0 – 200%
Measuring ApertureØ4–Ø30 mm (reflective); Ø25.4 mm (transmissive)
Measuring Time~2.4 s (SCI & SCE ~5 s)
Colorimetry
Color SpaceCIE LAB, XYZ, Yxy, LCh, LUV, Munsell, sRGB, HunterLab, DIN Lab99
ΔE FormulasΔE*ab, ΔE*94, ΔE*cmc, ΔE*00, DINΔE99, Hunter
Observer Angle2° / 10°
IlluminantsD65, A, C, D50, D55, D75, F1–F12, CWF, TL83/84 …
Accuracy
Repeatability (reflectance)SD ≤ 0.04% (400–700 nm)
Repeatability (ΔE*ab)SD ≤ 0.01
Inter-instrument ErrorΔE*ab ≤ 0.12
Display & Interface
Display7″ TFT LCD, Capacitive Touch
Data PortUSB + Bluetooth + Print serial
Storage5,000 standards; 40,000 samples
LanguageEN / CN + optional DE, FR, ES
Physical & Electrical
Dimensions L×W×H370 × 300 × 200 mm
WeightApprox. 9.6 kg
PowerAC 24V, 3A adapter
LED Life Span5 yrs / 3 million measurements
Environment
Operating0–40°C, 0–85% RH, Alt <2,000 m
Storage-20–50°C, 0–85% RH

Specifications are subject to change without notice.
